Electric viscometer , Model RC-35D

We use viscometers that routinely measure viscosity as a function of shear rate together with rheometers that can characterize the solid-like properties of the same material.API Tests Pre-programmed,6 presets 600, 300, 200, 100, 6, 3
Push button design for easy operation and better control
Quantity:
  • RC-35D
  • RIGCHINA
  • 130-35

Electric viscometer Model RC-35D ,Part No. 130-35


The development of instrumentation to measure material properties has paralleled our understanding of their molecular properties. We now use viscometers that routinely measure viscosity as a function of shear rate together with rheometers that can characterize the solid-like properties of the same material.

The RIGCHINA ® Model RC-35D Electric viscometer a new type direct indicating instruments, this is a doddle to control with its well-designed on-screen,the intelligence Single-Chip Computer system is commissioned in instruments which are available in 6 and 12 speed designs for use on either 50 Hz and 60HZ electrical power. The standard power source is 220 volts.



API Tests Pre-programmed

This rheometer is equipped with R1 Rotor Sleeve, B1 Bob, F1 Torsion Spring, and a stainless steel, sample cup for testing according to American Petroleum Institute Recommended Practice.



Push button design for easy operation and better control

Power: 220 VAC, 50/60 Hz

6 preset Speeds: 600, 300, 200, 100, 6, 3

Speed Accuracy: 0.001 rpm

Dial Accuracy: 0.5

Dial Resolution: 0.1

Sample Cup Volume : 500ml

Torsion Spring : F1

Rotor-Bob : R1, B1



RC Series Viscometer Specifications

Part No.

Model

Description   &Technical Parameters

Remarks

130-35

RC-35D

Speeds Range:6   preset(600,300,200,100,6,3)

Speed   Accuracy: 0.001 rpm

Dial   Accuracy: 0.5

Dial   Resolution: 0.1

Sample Cup   Volume : 500ml

Torsion   Spring : F1 (F.02 )

Rotor-Bob :   R1, B1

Operating   Temperature : 40℉  to 125℉ (4.4℃   to 52℃)

Power: 230   VAC, 50 (115VAC,60 Hz)

Size:   6.5" × 6" × 18" (16.5 × 15 × 46 cm)
  Weight: 30lb (14 kg)


130-12

RC-12D

Power: 220   VAC, 50/60 Hz

12 preset   Speeds: (600,300,200,180,100,90,60,30,6,3,2,1)

Dial   Accuracy: 0.5

Dial   Resolution: 0.1

Sample Cup   Volume : 500ml

Torsion   Spring : F1 (F.02 )

Rotor-Bob :   R1, B1

Operating   Temperature : 40℉  to 125℉ (4.4℃   to 52℃)

Size:   6.5" × 6" × 18" (16.5 × 15 × 46 cm)
  Weight: 30lb (14 kg)
